RV55 LTE-A Pro (Cat 12) 4G & Wi-Fi Vehicle Router (Dual SIM, up to 20 clients)

RV55 LTE-A Pro (Cat 12) 4G & Wi-Fi Vehicle Router (Dual SIM, up to 20 clients)
RV55 LTE-A Pro (Cat 12) 4G & Wi-Fi Vehicle Router (Dual SIM, up to 20 clients) - Image 2
RV55 LTE-A Pro (Cat 12) 4G & Wi-Fi Vehicle Router (Dual SIM, up to 20 clients) - Image 3

£649.00

The AirLink® RV55 delivers LTE and Wi-Fi connectivity for vehicles and remote fixed assets operating in harsh environments. With ultra-low power consumption, the RV55 is ideal for solar/battery powered installations.

As part of the AirLink Performance series, the RV55 is to support mission-critical systems in extremely harsh indoor, vehicle or exposed outdoor locations. It provides the ultimate combination of secure, cellular LTE and Wi-Fi performance, with high-availability and network agility in a ruggedized form-factor.

Key Features

  • LTE Cat-12
  • Dual Radio 2.4/5 GHz 802.11ac Wi-Fi
  • 30 channel dedicated GNSS
  • 1 Gigabit Ethernet ports (LAN/WAN)
  • Configurable GPIO
  • RS232



Description

The Sierra Wireless® AirLink® RV55 LTE-A Pro router is a compact, intelligent and fully-featured communications platform that provides real-time wireless capabilities for fixed and mobile applications. The RV55 use LTE with fall back to HSPA+ and other radio bands.

It is intended for use in industrial settings such as:

  • Remotely monitoring and controlling infrastructure and surveillance equipment on pipelines, meters, pumps and valves in any energy, utility, or industrial application
  • Tracking the location of heavy equipment and assets in the field
  • Providing reliable Internet access to a mobile workforce

Together with AirLink Complete, you have a one-stop enterprise networking solution to provision devices, monitor cellular data usage, and remotely maintain software versions and configurations. AirLink Complete combines best-in-class device management software through AirLink Management Service (ALMS), industry-leading technical support

Ideal Applications

Primary or backup network connectivity for:

  • Public Safety
  • Utilities
  • Environmental Monitoring
  • Commercial Fleets
  • Critical Infrastructure
Modem 4G (LTE Cat 12) with fall-back to HSPA+/UMTS/EDGE/GPRS/GSM
SIM Slots 2x SIM slot
GPS Yes
Accessories Included DC Power Supply
Ports 2x GigE, 1x USB 2.0 Micro-B Port, 1x Aux (GPIO/CAN), 1x 9-pin RS232 Serial.
Operating Temperature -30 °C to 70 °C
Antenna Connectors 2x Cellular, 2x Wi-Fi, 1x GNSS
Housing Aluminum die cast
Dimensions (mm) 119 x 85 x 33
WiFi Enabled Yes
Device Industry Use Cases Public Safety, Utilities, Environmental Monitoring, Commercial Fleets
Device Applications Failover Connectivity, In-Vehicle, Primary Connectivity

RV55 TechSpec

RV55 Info Sheet
