Power Output cable for CQ-family PCs

Description

This is a 30 cm length power output cable for the following CQ-family PCs:

• CQ30 and CQ50L PC – Cable provides:
  • 2 x Ground (Black)
  • 2 x 12V Output (Yellow)
  • 2 x Unimplemeted Digital Input (Blue)*
• CQ50 PC – Cable provides
  • 3 x Ground (Black)
  • 2 x 12V Output (Yellow)
• CQ50P PC – Cable provides:
  • 2 x Ground (Black)
  • 2 x 12V Output (Yellow)
  • 1 x Unimplemented Digital Output (Red)*
  • 1 x Unimplemented Digital Input (Blue)*

*Please note that the digital inputs / outputs mentioned here are not the PC’s advertised inputs/outputs, which are available on a separate DIO port which uses an industry-standard DB9 connector.  The cable detailed here is for the 12V power-output connector, which in some cases also includes one or more I/O lines whose functionality is not currently implemented.
